840 Series

These valves are superbly engineered for the most demanding OEM applications where ultra high speed, uncompromising reliability, and ultra long life are warranted.

The 300 LPM valves are used widely in sorting machines because they are so compact and the 12 mm width makes them easily stackable in a long manifold.

Features:

• Worldwide acceptance for its versatility, speed and life.
• Minimum useful life of 500 million.
• Available only in 2-position 2-way configurations.
• Response times < 1 m/S with speed-up control.
• 24 volt DC.
• Integrated electronics for speed-up.
• Operating frequency up to 250 HZ.
• Compact with high flow rate of 300 LPM.
• One or two controls.
• Can be body ported or manifold mounted.
• Insensitive to vibration.
• Repeatable operation throughout useful life.
• Low power consumption.
• Ideally suited for ultra-high speed sorting machines.
